The RediFit combines steel and fiberglass doors with our RediFlex adjustable frames, factory-installed weatherstripping, and threshold for a time-saving pre-hung solution.
RediKit is conveniently packaged for job sites requiring unassembled units or job sites supplying their own door. Installation is as easy as tilt, fasten, and trim.
RediFit: Pre-Installed RediFlex Package With Door Pre-Installed RediFlex
RediKit: Package Less Your Supplied Door
The RediFit™ combines steel and fiberglass doors with our RediFlex™adjustable frames, factory-installed weatherstripping, and threshold for a time-saving pre-hung solution.
A second option is our conveniently packaged RediKit™. RediKit™ is perfect for job sites requiring unassembled units or job sites supplying their own door!
• The strong-as-the-wall design that you trust gives building owners the security of a 20, 45, 60, or 90- minute fire rating with the beauty they demand.
• Redi-Kit™ and Redi-Fit™ engineered door frames feature precise corners and a unique preview hole for easy wood casing alignment or choose a standard steel and aluminum casing option.
• Kerf frame with factory-installed weatherstripping available as well as non-kerf (standard) frames.
• Installation is as easy as tilt, fasten and trim.
• Fits walls from 4” to 12-1/2” thick
• Redi-Fit™ meets the Wind Borne Debris Region standard set by the Florida Building Code.
• Wide selection of door options from commercial to residential.
• Factory-installed glass, as well as air-louvered kits, are available in a variety of styles and options.
• MATERIAL:
16 gauge A40 Galvanneal, 18 gauge (standard), and 20 gauge cold-rolled steel per ASTM A1008M-16 steel or A40 Galvanneal
• DOOR THICKNESS:
For use with 1-3/8″ or 1/-3/4” thickness doors
• WALL SIZE:
4″ to 12-1/4″ (1-1/4″ adjustments) to accommodate non-standard wall sizes
• STOP HEIGHT:
5/8″
• HINGE REINFORCEMENTS:
Prepared with three 3-1/2″, 4″, 4-1/2″ standard weight 10 gauge hinge reinforcements or 5″ heavyweight hinge reinforcements – see complete list on hinge prep tab
• STRIKE REINFORCEMENTS:
Prepared with 12 gauge 2-3/4″ T-Strike Prep Standard – see a complete list of options on strike reinforcement prep tab
• WEATHERSTRIP:
See the Weatherstrip tab for complete options.
• FINISHING:
Prefinished in eight standard colors. See the complete list on the Colors tab.
• FIRE RATING:
Embossed 90 minutes neutral and positive pressure fire label; wood or stud steel wall constructions. See the Fire Testing Tab.
• MATERIAL:
16 gauge A40 Galvanneal, 18 gauge (standard), and 20 gauge cold-rolled steel per ASTM A1008M-16 steel or A40 Galvanneal
• DOOR THICKNESS:
For use with 1-3/4” thickness doors
• WALL SIZE:
4″ to 12-1/4″ (1″ adjustments) to accommodate non-standard wall sizes
• STOP HEIGHT:
5/8″
• HINGE REINFORCEMENTS:
Prepared with three 3-1/2″, 4″, 4-1/2″ standard weight 10 gauge hinge reinforcements or 5″ heavyweight hinge reinforcements – see complete list on hinge prep tab
• STRIKE REINFORCEMENTS:
Prepared with 12 gauge 2-3/4″ T-Strike Prep Standard – see a complete list of options on strike reinforcement prep tab
• WEATHERSTRIP:
See the Weatherstrip tab for complete options.
• FINISHING:
Prefinished in eight standard colors. See the complete list on the Colors tab.
• FIRE RATING:
Embossed 90 minutes neutral and positive pressure fire label; wood or stud steel wall constructions. See the Fire Testing Tab.
(1) hinge side base
(1) strike side base
(1) header base
(1) sill
(1) installation instructions
(1) 17’ set of kerf foam weatherstrip
(1) Prehang bag:
(1) prehang bracket
(2) #6 x 1/2” TEK screw, zinc (frame side)
(2) #6 x 3/4” pan head truss screw (door side)
(4) #6 x 1-1/2” pan head Phillips type 17 face frame screw (vinyl riser screws)
(1) prehang bracket installation instructions
(1) Accessory bag:
(1-1/2 pair) 4 x 5/8” radius hinges (brass plain bearing)
(14) #10-24 x 1/2” machine screws (brass
(16) #10-24 wood screws (brass)
(2) corner seals
(5) self-adhesive corrugated spacers
(1) #10-24 x 1/2” machine screw (zinc)
(2) 3/4” wood screws (zinc)
(2) upright closures
(1) header closure
(1) aluminum extender (if requested)
(1) 3-in-1 hardware bag:
(1) 2-3/4” “T” strike package with screws (brass)
(1) deadbolt strike package with screws (brass)
(1) deadbolt cover (Ivory, Bright White, RF Brown, Prime Gray) with screws (brass)
(2) #10 x 1-1/2” flat head Phillips head screw (zinc) (extender screws)
Smooth steel doors are designed for strength, security, and durability. This premium, insulated door system is constructed with a steel-edge perimeter and resists cracking, splitting, warping, twisting, and rotting.
Fiberglass doors offer the beauty and versatility of wood doors but require less maintenance and have a longer lifespan. Fiberglass doors are the best solution and are not susceptible to weather damage, require less maintenance, and offer higher performance ratings.
Dunbarton frames and casing are designed to work together to offer the best commercial, industrial, and multi-family package. We offer casing in steel, aluminum, and S56 Colonial. However, you also have the option to use any wood trim you prefer. Additionally, all trims are available in our standard colors or custom color-matched to meet your job specifications!
Our steel casing is 1-1/2″ is standard on all RediFrame products except Kerf RediFlex.
The aluminum casing is an extruded casing designed with modern, sculpted lines in durable prefinished aluminum.
S56 Colonial casing is a true 2-1/4″ width casing that brings a traditional design to any project
Steal Casing
Aluminum Casing
S56 Colonial Casing
Our casing is easy to install but every so often it is necessary to uninstall and adjust. We recommend our Casing Tool available to order here. Please follow the instructions as indicated on the video!
Dunbarton’s Casing Corner Clips are designed to hide surface distortion and gaps. They are also designed to allow the casing to be removable in case of any changes. When installing casing on RediFrame and RediFlex frames, the supplied clips are designed to snap in place into both ends of the header casing. After installed, the clips help ensure the proper alignment of the miter between the header casing and jamb casing on our steel, aluminum, and S56 Colonial casing.
Note: The RediFrame system does not require crimping to hold the clip in place. The combination of the casing, frame lance, and clip design also makes sure the casing does not rattle during the operation of the door.
Aluminum & Steel Casing Corner
S56 Casing Corner
Aluminum & Steel Casing Corner
Note: Dunbarton only supplies T-Strike, Deadbolt, Flushbolt, and Rollerlatch. All other hardware is customer supplied.
Frames are prepped to your preferred manufacturer location (Ceco, Curries, Premier, etc.) or available to RF locations, commercial door locations, or custom locations. Electric strikes are prep only, hardware must be customer supplied.
Drawings below are standard RediFrame locations.
Single
Double
Hinge Backset:
3/16″
Hinge Depth:
Per Template
Template Hinge Pattern Only:
1/4″ or 5/8″ radius
Single
Double
Hinge Backset:
3/16″
Hinge Depth:
Per Template
Template Hinge Pattern Only:
1/4″ or 5/8″ radius
Single
Double
Hinge Backset:
3/16″
Hinge Depth:
Per Template
Template Hinge Pattern Only:
1/4″ only
5/8″ radius hinge prep available in template or non-template hole pattern; specify hinge when ordering
Single
Double
Hinge Backset:
1/4″
Hinge Depth:
Per Template
Template Hinge Pattern Only:
1/4″ only
5/8″ radius hinge prep available in template or non-template hole pattern; specify hinge when ordering
Single
Double
Hinge Backset:
1/4″
Hinge Depth:
Per Template
Template Hinge Pattern Only:
1/4″ only
5/8″ radius hinge prep available in template or non-template hole pattern; specify hinge when ordering
Single
Double
Hinge Backset:
1/4″
Hinge Depth:
.134 for standard weight hinge
Template Hinge Pattern Only:
.180″ for heavy weight hinge
Template hinge pattern only
Single
Double
Hinge Backset:
1/4″
Hinge Depth:
.134 for standard weight hinge
Template Hinge Pattern Only:
.180″ for heavy weight hinge
Template hinge pattern only
Dutch
Hinge Backset:
3/16″
Hinge Depth:
per template
Template Hinge Pattern Only:
1/4″ or 5/8″ radius
Dutch
Hinge Backset:
1/4″
Hinge Depth:
.134″ for standard weight hinge
Template Hinge Pattern Only:
1/4″ only
5/8″ radius hinge prep available in template or non-template hole pattern; specify hinge when ordering
Dutch
Hinge Backset:
1/4″
Hinge Depth:
.134″ for standard weight hinge
Template Hinge Pattern Only:
.180 for heavy weight hinge
Template hinge pattern only
Note: Dunbarton only supplies T-Strike, Deadbolt, Flushbolt, and Rollerlatch. All other hardware is customer supplied.
Frames are prepped to your preferred manufacturer location (Ceco, Curries, Premier, etc.) or available to RF locations, commercial door locations, or custom locations. Electric strikes are prep only, hardware must be customer supplied.
Drawings below are standard RediFrame locations.
Colors may vary by screen!
Brass
US3
Oil Rubbed Bronze
US10B
Flat Black
US19
Dull Chrome
US26
Note: Dunbarton only supplies T-Strike, Deadbolt, Flushbolt, and Rollerlatch. All other hardware is customer supplied.
Frames are prepped to your preferred manufacturer location (Ceco, Curries, Premier, etc.) or available to RF locations, commercial door locations, or custom locations. Electric strikes are prep only, hardware must be customer supplied.
Drawings below are standard RediFrame locations.
| SIZE | TYPE | FRAME DEPTH | DOOR SIZE | REDIFRAME | KERF RF | REDIFLEX | KERF RFX | TEMPLATE |
|---|---|---|---|---|---|---|---|---|
| 1-1/4” X 2-3/4” | “T” Strike Emboss (1-3/8” door) | .110 | 1-3/8″ | ____ | ____ | Download | ||
| 1-1/4” X 2-3/4” | “T” Strike Emboss (1-3/4” door) | .110 | 1-3/4″ | Download | ||||
| 1-1/4” X 4-7/8” | “ASA” Adjustable Strike Emboss (1-3/4” door) | .125 | 1-3/4″ | * | * | * | * | Download |
| 1-1/8” X 2-3/4” | Deadbolt Strike Emboss | .110 | 1-3/4″ | ** | ** | ** | ** | Download |
| 1-1/2” X 2-1/4” | Full Lip Strike | .110 | 1-3/4″ | * | * | * | * | Download |
Note: Dunbarton only supplies T-Strike, Deadbolt, Flushbolt, and Rollerlatch. All other hardware is customer supplied.
Frames are prepped to your preferred manufacturer location (Ceco, Curries, Premier, etc.) or available to RF locations, commercial door locations, or custom locations. Electric strikes are prep only, hardware must be customer supplied.
Drawings below are standard RediFrame locations.
| TYPE | DESCRIPTION | TEMPLATE |
|---|---|---|
| ELECTRIC STRIKE | Adams Rite 74R1 | Supply from Manuf. |
| ELECTRIC STRIKE | Adams Rite 7140 | Supply from Manuf. |
| ELECTRIC STRIKE | Adams Rite 7240 | Supply from Manuf. |
| ELECTRIC STRIKE | Dorma ES72 | Supply from Manuf. |
| ELECTRIC STRIKE | Hager 2925 | Supply from Manuf. |
| ELECTRIC STRIKE | HES 1006 | Supply from Manuf. |
| ELECTRIC STRIKE | HES 4500 | Supply from Manuf. |
| ELECTRIC STRIKE | HES 5000 | Supply from Manuf. |
| ELECTRIC STRIKE | HES 5200 | Supply from Manuf. |
| ELECTRIC STRIKE | HES 8000 | Supply from Manuf. |
| ELECTRIC STRIKE | 8300 | Supply from Manuf. |
| ELECTRIC STRIKE | HES Vista | Supply from Manuf. |
| ELECTRIC STRIKE | Locktronics CS450/750 | Supply from Manuf. |
| ELECTRIC STRIKE | RCI F4111 | Supply from Manuf. |
| ELECTRIC STRIKE | Trine EN400 | Supply from Manuf. |
| ELECTRIC STRIKE | Trine 4200 | Supply from Manuf. |
| ELECTRIC STRIKE | Von Duprin 4200 | Supply from Manuf. |
| ELECTRIC STRIKE | Von Duprin 4200 | Supply from Manuf. |
| ELECTRIC STRIKE | Von Duprin 5100 | Supply from Manuf. |
Note: Dunbarton only supplies T-Strike, Deadbolt, Flushbolt, and Rollerlatch. All other hardware is customer supplied.
Frames are prepped to your preferred manufacturer location (Ceco, Curries, Premier, etc.) or available to RF locations, commercial door locations, or custom locations. Electric strikes are prep only, hardware must be customer supplied.
Drawings below are standard RediFrame locations.
Single
Double
Hinge Backset:
3/16″
Hinge Depth:
Per Template
Template Hinge Pattern Only:
1/4″ or 5/8″ radius
Single
Double
Hinge Backset:
3/16″
Hinge Depth:
Per Template
Template Hinge Pattern Only:
1/4″ or 5/8″ radius
Single
Double
Hinge Backset:
3/16″
Hinge Depth:
Per Template
Template Hinge Pattern Only:
1/4″ only
5/8″ radius hinge prep available in template or non-template hole pattern; specify hinge when ordering
Single
Double
Hinge Backset:
1/4″
Hinge Depth:
Per Template
Template Hinge Pattern Only:
1/4″ only
5/8″ radius hinge prep available in template or non-template hole pattern; specify hinge when ordering
Single
Double
Hinge Backset:
1/4″
Hinge Depth:
Per Template
Template Hinge Pattern Only:
1/4″ only
5/8″ radius hinge prep available in template or non-template hole pattern; specify hinge when ordering
Single
Double
Hinge Backset:
1/4″
Hinge Depth:
.134 for standard weight hinge
Template Hinge Pattern Only:
.180″ for heavy weight hinge
Template hinge pattern only
Single
Double
Hinge Backset:
1/4″
Hinge Depth:
.134 for standard weight hinge
Template Hinge Pattern Only:
.180″ for heavy weight hinge
Template hinge pattern only
Dutch
Hinge Backset:
3/16″
Hinge Depth:
per template
Template Hinge Pattern Only:
1/4″ or 5/8″ radius
Dutch
Hinge Backset:
1/4″
Hinge Depth:
.134″ for standard weight hinge
Template Hinge Pattern Only:
1/4″ only
5/8″ radius hinge prep available in template or non-template hole pattern; specify hinge when ordering
Dutch
Hinge Backset:
1/4″
Hinge Depth:
.134″ for standard weight hinge
Template Hinge Pattern Only:
.180 for heavy weight hinge
Template hinge pattern only
Note: Dunbarton only supplies T-Strike, Deadbolt, Flushbolt, and Rollerlatch. All other hardware is customer supplied.
Frames are prepped to your preferred manufacturer location (Ceco, Curries, Premier, etc.) or available to RF locations, commercial door locations, or custom locations. Electric strikes are prep only, hardware must be customer supplied.
Drawings below are standard RediFrame locations.
Colors may vary by screen!
Brass
US3
Oil Rubbed Bronze
US10B
Flat Black
US19
Dull Chrome
US26
Note: Hinges are supplied when requested. Frames are prepped to your preferred manufacturer location (Ceco, Curries, Premier, etc.) or available to RF locations, commercial door locations, or custom locations.
Electric hinges and EPT hinges are prep only, hardware must be customer supplied.
Drawings below are standard RediFrame locations.
| SIZE | TYPE | FRAME DEPTH | DOOR THICKNESS | REDIFRAME | KERF RF | REDIFLEX | KERF RFX | TEMPLATE |
|---|---|---|---|---|---|---|---|---|
| 3-1/2″ | 1/4″ Radius Corner (1-3/8″ door) | .120 | 1-3/8″ | ________ | Download | |||
| 3-1/2″ | Square* | .120 | 1-3/8″ | Download | ||||
| 3-1/2″ | 5/8″ Radius Corner (1-3/8″ door) | .120 | 1-3/8″ | * | ________ | * | ________ | Download |
| 4″ | 1/4″ Radius Corner | .125 | 1-3/4″ | Download | ||||
| 4″ | 5/8″ Radius UHP | .115 | 1-3/4″ | Download | ||||
| 4″ | UHP #5: Taylor|Perma Door, Therma Tru, Jeld-Wen, Ceco | .115 | 1-3/4″ | Download | ||||
| 4″ | UHP #6: Stanley, Masonite, Challenge, Castlegate | .125 | 1-3/4″ | Download | ||||
| 4-1/2″ | Square Corner Std. Weight | .134 | 1-3/4″ | Download | ||||
| 4-1/2″ | Square Corner Heavy Weight | .180 | 1-3/4″ | ** | ** | ** | ** | Download |
| 5″ | Square Corner Std. Weight | .145 | 1-3/4″ | ** | ** | ** | ** | Download |
| 5″ | Square Corner Heavy Weight | .190 | 1-3/4″ | ** | ** | ** | ** | Download |
Note: Hinges are supplied when requested. Frames are prepped to your preferred manufacturer location (Ceco, Curries, Premier, etc.) or available to RF locations, commercial door locations, or custom locations.
Electric hinges and EPT hinges are prep only, hardware must be customer supplied.
Drawings below are standard RediFrame locations.
| NAME | STYLE | TEMPLATE |
|---|---|---|
| Continuous Hinge Reinforcement | Full Length | Supply from Manuf. |
Note: Hinges are supplied when requested. Frames are prepped to your preferred manufacturer location (Ceco, Curries, Premier, etc.) or available to RF locations, commercial door locations, or custom locations.
Electric hinges and EPT hinges are prep only, hardware must be customer supplied.
Drawings below are standard RediFrame locations.
| SIZE | NAME | STYLE | TEMPLATE |
|---|---|---|---|
| 4″ | Square Standard Weight Electric Hinge | Hager | Supply from Manuf. |
| 4-1/2″ | Square Standard Weight Electric Hinge | Hager | Supply from Manuf. |
| 4-1/2″ | Square Standard Weight Electric Hinge | Ives | Supply from Manuf. |
| 4-1/2″ | Square Standard Weight Electric Hinge | McKinney-Single Pole | Supply from Manuf. |
| 4-1/2″ | Square Standard Weight Electric Hinge | McKinney-Dual Pole | Supply from Manuf. |
| 4-1/2″ | Square Standard Weight Electric Hinge | Stanley | Supply from Manuf. |
| 4-1/2″ | Square Heavy Weight Electric Hinge | Hager | Supply from Manuf. |
| 4-1/2″ | Square Heavy Weight Electric Hinge | Ives | Supply from Manuf. |
| 4-1/2″ | Square Heavy Weight Electric Hinge | McKinney-Single Pole | Supply from Manuf. |
| 4-1/2″ | Square Heavy Weight Electric Hinge | McKinney-Dual Pole | Supply from Manuf. |
| 4-1/2″ | Square Heavy Weight Electric Hinge | Stanley | Supply from Manuf. |
| 4-1/2″ | Square Heavy Weight Electric Hinge | Hager | Supply from Manuf. |
| NAME | STYLE | TEMPLATE |
|---|---|---|
| ABH | EPT ABH PT105 | Supply from Manuf. |
| IVES | EPT Ives EPT10 | Supply from Manuf. |
Note: Dunbarton only supplies T-Strike, Deadbolt, Flushbolt, and Rollerlatch. All other hardware is customer supplied.
| TYPE | DESCRIPTION | SINGLE | PAIR | TEMPLATE |
|---|---|---|---|---|
| T-STRIKE | T-Strike (1-3/4″ door) | ____ | Download | |
| T-STRIKE | T-Strike (1-3/8″ door) | Download | ||
| ROLLER LATCH | Rockwood 911 Roller Latch | * | * | Download |
| FLUSH BOLT | Reversible Flush Bolt | ** | ** | Download |
| FLUSH BOLT | DCI 960 Flush Bolt | Supply from Manuf. | ||
| FLUSH BOLT | DON-JO 1557 Flush Bolt | Supply from Manuf. | ||
| FLUSH BOLT | Hager 282D Flush Bolt | Supply from Manuf. | ||
| FLUSH BOLT | Hager 283D Flush Bolt | Supply from Manuf. | ||
| FLUSH BOLT | Hager 292D Flush Bolt | Supply from Manuf. | ||
| FLUSH BOLT | Rockwood 555 Flush Bolt | Supply from Manuf. | ||
| FLUSH BOLT | Sargent 650 Flush Bolt | Supply from Manuf. |
Note: Dunbarton only supplies T-Strike, Deadbolt, Flushbolt, and Rollerlatch. All other hardware is customer supplied.
| TYPE | DESCRIPTION | SINGLE | PAIR | TEMPLATE |
|---|---|---|---|---|
| CVR | Dorma 418 | ____ | Download | |
| CVR | Falcon 4188 | Supply from Manuf. | ||
| CVR | Falcon 25 | * | * | Supply from Manuf. |
| CVR | Hager 4500 | ** | ** | Supply from Manuf. |
| CVR | Von Duprin 338 2-14″ CL | Supply from Manuf. | ||
| CVR | Von Duprin 338 2-13/16″ CL | Supply from Manuf. |
Note: Dunbarton only supplies T-Strike, Deadbolt, Flushbolt, and Rollerlatch. All other hardware is customer supplied.
| TYPE | DESCRIPTION | SINGLE | PAIR | TEMPLATE |
|---|---|---|---|---|
| OVERHEAD STOP | ABH 1000 | ____ | Supply from Manuf. | |
| OVERHEAD STOP | ABH 1000SL | Supply from Manuf. | ||
| OVERHEAD STOP | Glynn Johnson 100 | * | * | Supply from Manuf. |
| OVERHEAD STOP | Glynn Johnson 100CJ | ** | ** | Supply from Manuf. |
| OVERHEAD STOP | Glynn Johnson 410 | Supply from Manuf. | ||
| OVERHEAD STOP | Hager 6000 | Supply from Manuf. | ||
| OVERHEAD STOP | Hager 7000 | Supply from Manuf. | ||
| OVERHEAD STOP | Rixon Series 1 | Supply from Manuf. | ||
| OVERHEAD STOP | Rixon Series 2 | Supply from Manuf. | ||
| OVERHEAD STOP | Rixon Series 5 | Supply from Manuf. | ||
| OVERHEAD STOP | Rixon Series 6 | Supply from Manuf. | ||
| OVERHEAD STOP | Rixon Series 6 ADJ | Supply from Manuf. | ||
| OVERHEAD STOP | Rockwood 1100 | Supply from Manuf. | ||
| OVERHEAD STOP | Rockwood 1100SL | Supply from Manuf. | ||
| OVERHEAD STOP | Rockwood 14000 | Supply from Manuf. |
Note: Dunbarton only supplies T-Strike, Deadbolt, Flushbolt, and Rollerlatch. All other hardware is customer supplied.
| TYPE | DESCRIPTION | SINGLE | PAIR | TEMPLATE |
|---|---|---|---|---|
| WELD PAR ARM | Single | ____ | Supply from Manuf. | |
| WELD PAR ARM | Pair | Supply from Manuf. | ||
| WELD PAR ARM | Pair with 1 SVR | * | * | Supply from Manuf. |
| WELD PAR ARM | Pair with 2 SVR-2DE | ** | ** | Supply from Manuf. |
| CONCEALED CLOSERS | Dorma 912 Single | Pair | Download | ||
| CONCEALED CLOSERS | Dorma 712 Single | Pair | Supply from Manuf. | ||
| CONCEALED CLOSERS | Glen John 450 Single | Pair | Supply from Manuf. | ||
| CONCEALED CLOSERS | ITS96 Single | Pair | Supply from Manuf. | ||
| CONCEALED CLOSERS | LCN 6030 Single | Supply from Manuf. |
Dunbarton’s 90-minute fire-rated weatherstripping is available in three colors: white, brown, and beige. The easy-to-install kerf weatherstripping comes ready to install on-site or is available pre-installed. Be sure to specify weatherstripping when ordering kerf frames.
Weatherstrip 500 Reach
Weatherstrip 650 Reach
Weatherstrip 750 Reach
White
Brown
Beige
The purpose of a threshold is to close the gap between the bottom of a door and the floor. Thresholds are used with door bottoms and weatherstripping to seal the opening, preventing air, rain, and snow from entering. Dunbarton has four standard styles with two extenders for the fixed inswing, with other options available.
FASTENERS: #10 x 1-1/2” flat head Phillips screws, provided. Other screw types and anchors are available upon request.
FINISH: Mill
MATERIAL: 6063-T6 Aluminum
WIDTH: See profile Tech Sheet for details
A complete guide for each style below in yellow.
ADA Saddle Sill
ADA Tile Face
Bumper Outswing Sill
Fixed Inswing Sill
3/4″ Extender for Fixed Inswing Sill
2″ Extender for Fixed Inswing Sill
Colors may vary by monitor! Color chips are available upon request. Click here to order.
RediFrame Brown
Bright White
Ivory
Mojave Brown
Black
Light Gray
Tan
Alusteel
*Standard optional colors include an upcharge.
Prime Gray**
**Prime gray not intended for top coat
Dunbarton is able to custom color match. Submit a color chip for matching. Consult the factory for pricing and lead times. Dunbarton is able to color match any Benjamin Moore™ or Sherwin Williams™ Color.
Below is a list of specific colors recently matched.
| SHERWIN WILLIAMS & BENJAMIN MOORE NUMBERS | COLOR SHADE | CALDWELL NUMBERS |
|---|---|---|
| WHITES AND WHITE SHADES | ||
| SW6385 | DOVER WHITE | 721-5001 |
| SW7012 | CREAMY | 721-5144 |
| SW0050 | CLASSIC LIGHT BUFF | 721-5164 |
| SW6119 | ANTIQUE WHITE | 721-5177 |
| SW7006 | EXTRA WHITE | 721-5314 |
| SW7005 | PURE WHITE | 721-5493 |
| SW6140 | MODERATE WHITE | 721-5876 |
| SW7102 | WHITE FLOWER | 721-6310 |
| SW7056 | RESERVED WHITE | 721-6625 |
| SW7627 | WHITE HERON | 721-6963 |
| SW7757 | HIGH REFLECTIVE WHITE | 721-7085 |
| SW7009 | PEARLY WHITE | 721-7155 |
| SW7035 | AESTHETIC WHITE | 721-7187 |
| SW6000 | SNOWFALL | 721-7221 |
| SW7004 | SNOWBOUND | 721-7240 |
| SW7661 | REFLECTION | 721-7307 |
| SW6168 | MODERNE WHITE | 721-7332 |
| SW7042 | SHOJI WHITE | 721-6574 |
| SW7671 | ON THE ROCK | 721-7612 |
| SW7551 | GREEK VILLA | 721-7748 |
| SW2423 | POLAR WHITE | 721-7878 |
| SW7103 | WHITETAIL | 721-7899 |
| SW0053 | PORCELAIN | 721-7920 |
| BM915 | CAMEO WHITE | 721-6528 |
| BM OC-66 | SNOW WHITE | 721-6449 |
| BM OC-38 | ACADIA WHITE | 721-6586 |
| BM968 | DUNE WHITE | 721-6588 |
| BM OC-17 | WHITE DOVE | 721-6779 |
| BM 0C-141 | CHINA WHITE | 721-6821 |
| BM 0C-118 | SNOWFALL WHITE | 721-6954 |
| BM 2121-70 | CHANTILLY LACE | 721-6990 |
| BM AC-41 | ACADIA WHITE | 721-6998 |
| BM OC-69 | WHITE OPPULENCE | 721-7097 |
| BM2122-70 | SNOW WHITE | 721-7131 |
| BM OC-25 | CLOUD COVER | 721-7225 |
| BM OC-138 | WHITE DRIFTS | 721-7411 |
| BM2145-70 | COTTON BALLS | 721-7487 |
| BM OC-149 | DECORATORS WHITE | 721-7650 |
| BM OC-62 | BABY’S BREATH | 721-7653 |
| BM2146-70 | AURA BAVARIAN CREAM | 721-7684 |
| GRAY AND GRAY SHADES | ||
| SW7016 | MINDFUL GRAY | 723-5915 |
| SW7019 | GAUNTLET GRAY | 723-6031 |
| SW7065 | ARGOS | 723-6502 |
| SW7030 | ANEW GRAY | 723-6128 |
| SW7675 | SEALSKIN | 723-6274 |
| SW7029 | AGREEABLE GRAY | 723-6424 |
| SW7044 | AMAZING GRAY | 723-6544 |
| SW7018 | DOVETAIL | 723-6656 |
| SW7076 | CYBERSPACE GRAY | 723-6659 |
| SW7015 | REPOSE GRAY | 723-6690 |
| SW7023 | REQUISITE GRAY | 723-6794 |
| SW7069 | IRON ORE GRAY | 723-6825 |
| SW7504 | KEYSTONE GRAY | 723-6828 |
| SW7024 | FUNCTIONAL GRAY | 723-6899 |
| SW7624 | SLATE TILE | 723-6958 |
| SW7674 | PEPPERCORN | 723-6969 |
| SW8302 | GREAT GRAPHITE | 723-6979 |
| SW7022 | ALPACA | 723-6995 |
| SW7068 | GRIZZLE GRAY | 723-7058 |
| SW2849 | WESTCHESTER GRAY | 723-7119 |
| SW7075 | WEB GRAY | 723-7164 |
| SW7673 | PEWTER CAST | 723-7177 |
| SW2848 | ROYCROFT PEWTER | 723-7182 |
| SW6071 | POPULAR GRAY | 723-7252 |
| SW7043 | WORLDLY GRAY | 723-7264 |
| SW7051 | ANALYTICAL GRAY | 723-7270 |
| SW6001 | GRAYISH | 723-7324 |
| SW9170 | ACIER | 723-7311 |
| SW9171 | FELTED WOOL | 723-7315 |
| SW6001 | GRAYISH | 723-7324 |
| SW7641 | COLONNADE GRAY | 723-7362 |
| SW7017 | DORIAN GRAY | 723-7552 |
| SW7672 | KNITTING NEEDLES | 723-7573 |
| SW7634 | PEDIMENT | 723-7582 |
| SW7066 | GRAY MATTERS | 723-7599 |
| SW9162 | AFRICAN GRAY | 723-7682 |
| SW9168 | ELEPHANT EAR | 723-7707 |
| SW7658 | GRAY CLOUDS | 723-7755 |
| SW7654 | LATTICE | 723-7814 |
| SW0037 | MORRIS ROOM GRAY | 723-7845 |
| SW6236 | GRAYS HARBOR | 723-7848 |
| SW7644 | GATEWAY GRAY | 723-7857 |
| SW7663 | MONORAIL SILVER | 723-7891 |
| BM217-40 | DRIFTWOOD | 723-4706 |
| BM HC-166 | KENDALL CHARCOAL | 723-6395 |
| BM2121-20 | STEEL WOOL | 723-6636 |
| BM1462 | GRAY MOUNTAIN | 723-6887 |
| BM2124-10 | WROUGHT IRON | 723-6992 |
| BM AC-27 | GALVESTON GRAY | 723-7013 |
| BM2024-60 | LEMONADE | 721-7113 |
| BM OC-26 | SILVER SATIN | 723-7040 |
| BM2138-60 | GRAY CASHMERE | 723-7138 |
| BM1603 | GRAPHITE | 723-7191 |
| BM2134-30 | IRON MOUNTAIN | 723-7206 |
| BM AF-700 | STORM | 723-7227 |
| BM1616 | STORMY SKY | 723-7266 |
| BM2108-50 | SILVER FOX | 723-7274 |
| BM1475 | GRAYSTONE | 723-7341 |
| BM2112-50 | STORMY MONDAY | 723-7343 |
| BM CC-636 | MOUNTAIN AIR | 723-7419 |
| BM1610 | FRENCH BERET | 723-7421 |
| BM1595 | ROCKY COAST | 723-7497 |
| BM 179 | PLATINUM GRAY | 723-7672 |
| BM1557 | SILVER SONG | 723-7713 |
| BM2134-50 | GULL WING GRAY | 723-7720 |
| YELLOWS AND YELLOW SHADES | ||
| SW7732 | LEMON GRASS | 724-7618 |
| SW6699 | CRISPY GOLD | 724-7716 |
| BM239 | IVORY PORCELAIN | 724-6817 |
| ORANGE | ||
| SW6328 | FIREWEED | 725-7636 |
| BEIGES AND BROWNS AND BROWN SHADES | ||
| SW7008 | ALABASTER | 726-4960 |
| SW6117 | SMOKY TOPAZ | 726-5122 |
| SW7048 | URBANE BRONZE | 726-5451 |
| SW7038 | TONY TAUPE | 726-5487 |
| SW6006 | BLACK BEAN | 726-5528 |
| SW6142 | MACADAMIA | 726-5587 |
| SW6090 | JAVA | 726-5703 |
| SW6121 | WHOLE WHEAT | 726-5705 |
| SW7013 | IVORY LACE | 726-5750 |
| SW7011 | NATURAL CHOICE | 726-5754 |
| SW7031 | MEGA GREIGE | 726-5760 |
| SW7506 | LOGGIA | 726-5770 |
| SW7046 | ANONYMOUS | 726-5774 |
| SW6104 | KAFFEE | 726-5801 |
| SW6102 | PORTABELLO | 726-5922 |
| SW6136 | HARMONIC TAN | 726-6043 |
| SW7049 | NUANCE | 726-6101 |
| SW7036 | ACCESSIBLE BEIGE | 726-6145 |
| SW6076 | TURKISH COFFEE | 726-6225 |
| SW7693 | STONEBRIAR | 726-6303 |
| SW7631 | CITY LOFT | 726-6308 |
| SW6041 | OTTER | 726-6328 |
| SW7067 | CITYSCAPE | 726-6344 |
| SW7026 | GRIFFIN | 726-6352 |
| SW6068 | BREVITY BROWN | 726-6386 |
| SW7047 | PORPOISE | 726-6442 |
| SW6070 | HERON PLUME | 726-6458 |
| SW7037 | BALANCED BEIGE | 726-6473 |
| SW6138 | ARTIFACT | 726-6541 |
| SW6150 | UNIVERSAL KHAKI | 726-6606 |
| SW6083 | SABLE | 726-6679 |
| SW7025 | BACKDROP | 726-6792 |
| SW7063 | PERFECT GREIGE | 726-6832 |
| SW6078 | REALISTIC BEIGE | 726-6889 |
| SW7511 | BUNGALOW BEIGE | 726-6891 |
| SW6101 | SAND OF TIME | 726-6893 |
| SW7633 | TAUPE TONE | 726-7000 |
| SW8025 | PALE BROWN | 726-7015 |
| SW7642 | PAVESTONE | 726-7060 |
| SW1028 | KOHL | 726-7067 |
| SW2735 | ROCKWEED | 726-7091 |
| SW9084 | COCOA WHIP | 726-7129 |
| SW7032 | WARM STONE | 726-7302 |
| SW6395 | ALCHEMY | 726-7334 |
| SW7533 | KHAKI SHADE | 726-7382 |
| SW6103 | TEA CHEST | 726-7548 |
| SW9166 | DRIFT OF MIST | 726-7570 |
| SW7618 | DEEP SEA DIVE | 726-7645 |
| SW7509 | TIKI HUT | 726-7688 |
| SW7508 | TAVERN TAUPE | 726-7690 |
| SW6097 | STURDY BROWN | 726-7700 |
| BM 0C-10 | WHITE SAND | 726-5520 |
| BM HC-80 | BLEEKER BEIGE | 726-6360 |
| BM 1527 | GOING TO THE CHAPEL | 726-6372 |
| BM2097-10 | TOASTED BROWN | 726-6619 |
| BM AF-685 | THUNDER | 726-6643 |
| BM2106-10 | JAVA | 726-6695 |
| BM1092 | GLAZED PEAR | 726-6697 |
| BM HC-76 | DAVENPORT TAN | 726-6705 |
| BM2114-10 | BITTERSWEET CHOCOLATE | 726-6781 |
| BM860 | APPARITION | 726-7035 |
| BM1543 | PLYMOUTH ROCK | 726-7050 |
| BMOC6 | FEATHER DOWN | 726-7150 |
| BM OC-32 | TAPESTRY BEIGE | 726-7384 |
| BM2103-10 | NATURAL BROWN | 726-7393 |
| BM HC-92 | WHEELING NEUTRAL | 726-7661 |
| BM2111-20 | GRIZZLY BEAR BROWN | 726-7678 |
| BM972 | ALASKAN SKIES | 726-7746 |
| GREENS | ||
| SW6720 | PARADISE | 727-7262 |
| SW6488 | GRAND CANAL | 727-7765 |
| SW6209 | RIPE OLIVE | 727-7837 |
| BM145 | AVOCADO | 727-7006 |
| BLUES | ||
| SW6230 | RAIN STORM | 728-7313 |
| SW7604 | SMOKEY BLUE | 728-7524 |
| SW6244 | NAVAL | 728-7655 |
| SW6965 | HYPER BLUE | 728-7904 |
| SW9178 | IN THE NAVY | 728-7806 |
| BMCC-392 | NORTH SEA | 728-7115 |
| BM HC-148 | JAMESTOWN BLUE | 728-7405 |
| BM 16666 | IN THE MIDNIGHT HOUR | 728-7409 |
| BM2135-40 | PROVINCE BLUE | 728-7491 |
| BLACKS | ||
| SW6258 | TRICORN BLACK | 729-5567 |
| SW7020 | BLACK FOX | 729-6064 |
| SW6991 | BLACK MAGIC | 729-6910 |
| SW6993 | BLACK OF NIGHT | 729-7604 |
| SW6990 | CAVIAR | 729-7850 |
| BM2130-30 | ALMOST BLACK | 729-7489 |
| BM2128-10 | BLACK BEAUTY | 729-7811 |
Dunbarton is a registered trademark of Dunbarton Corporation. Rediframe and all other marks where denoted are registered trademarks of Dunbarton Corporation
